Product Features: | |
Application: | Off shore or anchor for ship |
Material: | Alloy steel Q355,Casting |
Specification: | 300kgs to 10000kgs |
Surface: | Hot dip galvanizing |
Standard: | European standard/USA ASTM 80 |
Certificate: | LR, ABS, BV, DNV, CCS, KR, NK, RMRS,etc |
The definition of a large grip anchor is that the grip force is greater than twice the grip force of an ordinary rodless anchor of the same weight under the same offshore grip test conditions, while the common ordinary rodless anchor Hall anchor has a grip weight ratio of about 3-4 times,from which it can be inferred that the grip ratio of the delta anchor is at least 6-8 times.
However, the actual parameters show that the grab-weight ratio of the delta anchor can reach up to 30-35 times,but the general selection is recommended to be 10 times, and the grab-to-weight ratio selected by the anchor factory is 16-20 times.
Norminal | SIZE(mm) | |||||
Weight(kg) | A | B | D | C | E | F |
300 | 1200 | 960 | 1080 | 457 | 1380 | 45 |
500 | 1500 | 1200 | 1350 | 571 | 1725 | 50 |
1000 | 1875 | 1500 | 1686 | 714 | 2155 | 62 |
1080 | 1915 | 1530 | 1686 | 722 | 2200 | 62 |
2000 | 2363 | 1890 | 2124 | 900 | 2715 | 82 |
3000 | 2700 | 2160 | 2430 | 1028 | 3105 | 90 |
4000 | 2975 | 2380 | 2650 | 1130 | 3395 | 100 |
5000 | 3250 | 2600 | 2922 | 1238 | 3735 | 110 |
7000 | 3575 | 2860 | 3216 | 1361 | 4116 | 117 |
8000 | 3730 | 2900 | 3360 | 1420 | 4300 | 130 |
9000 | 3950 | 3160 | 3555 | 1504 | 4543 | 135 |
10000 | 4100 | 3280 | 3690 | 1561 | 4715 | 140 |
12000 | 4300 | 3440 | 3942 | 1638 | 5017 | 145 |
15000 | 4845 | 3875 | 4355 | 1830 | 5513 | 150 |
18000 | 5140 | 4080 | 4610 | 1940 | 6080 | 160 |
20000 | 5330 | 4260 | 4790 | 2010 | 6310 | 170 |
25000 | 5740 | 4590 | 5160 | 2165 | 6532 | 195 |
30000 | 6100 | 4880 | 5486 | 2305 | 7225 | 195 |
40000 | 6715 | 5370 | 6036 | 2536 | 7948 | 210 |
50000 | 7230 | 5785 | 6500 | 2730 | 8560 | 225 |
60000 | 7690 | 6150 | 6910 | 2940 | 9100 | 240 |
70000 | 8095 | 6475 | 7275 | 3060 | 9580 | 250 |
80000 | 8460 | 6770 | 7610 | 3195 | 10020 | 260 |
90000 | 8800 | 7040 | 7910 | 3325 | 10420 | 270 |
100000 | 9100 | 7285 | 8190 | 3440 | 10780 | 280 |
