Application:Mooring,Marine,Ship
Application:Mooring,Marine,Ship
Application: Aquaculture, Fish farm mooring
AC-14 anchor is a stockless HHP anchor with a wide anchor crown, thick and long flukes, and longitudinal ribs.
ADA aqua drag anchor is improved version base on generation of aqua-moor DSA anchor, yet provides better performance.
Application:Lifting accessory commonly used in industrial and construction settings.
Product Features: | |
Specification: | For rope from 48mm to 115mm |
Size: | 6” to 14” |
Material: | Carbon steel |
Process: | Casting |
Surface treatment: | Hot-dip galvanized |
SPEC | A (mm) | N (mm) | P(mm) | K(mm) | D(mm) | E(mm) | R(mm) | F(mm) |
6ʺ | 152 | 120 | 75 | 115 | 7 | 31 | 48 | 40 |
7ʺ | 178 | 140 | 85 | 140 | 7 | 35 | 56 | 55 |
8ʺ | 203 | 160 | 105 | 160 | 8 | 40 | 64 | 55 |
9ʺ | 229 | 180 | 110 | 175 | 10 | 46 | 72 | 65 |
10ʺ | 254 | 200 | 120 | 190 | 10 | 50 | 80 | 70 |
11ʺ | 279 | 220 | 145 | 210 | 12 | 57 | 88 | 65 |
12ʺ | 305 | 245 | 150 | 230 | 14 | 65 | 102 | 80 |
14ʺ | 356 | 300 | 170 | 290 | 14 | 72 | 115 | 12 |
